Khoom Mould
Yam khoom Mould yog dab tsi
Cov khoom lag luam pwm, tseem hu ua cov khoom lag luam yas pwm, hais txog ib hom kev txhaj tshuaj siv los ua cov khoom yas uas suav tias yog cov khoom lag luam. Cov no feem ntau yog cov khoom tsim tawm nrog kev thov siab thiab cov qauv tsim qauv, feem ntau siv hauv cov khoom siv niaj hnub.
Cov ntsiab lus ntawm Cov Khoom Muag Pwm
Cov khoom lag luam pwm yog tsim los rau kev ua haujlwm zoo thiab kev ua haujlwm zoo, txhawm rau tsim kom muaj ntau qhov chaw nrog qhov zoo ib yam ntawm tus nqi qis ib-ntu. Lawv feem ntau siv hauv kev lag luam xws li ntim khoom, tsev neeg, kichenwares, khoom siv hluav taws xob, tsheb thauj mus los thiab lwm yam. Piv txwv ntawm cov khoom tsim los ntawm cov khoom siv pwm muaj xws li ntim, thoob, khob, tais diav, crates, basins, rooj tog thiab ntau yam khoom siv hauv tsev.
Kev tsim thiab kev tsim cov khoom lag luam pwm yog qhov tseem ceeb xws li kev tsim khoom sai, ua haujlwm ntev, thiab kev saib xyuas yooj yim. Lawv tuaj yeem siv cov ntaub ntawv zoo li cov hlau tawv tawv, nyob ntawm qhov ntim ntau lawm thiab cov nqi txiav txim siab. Tsis tas li ntawd, cov khoom lag luam pwm feem ntau yog tsim los rau cov txheej txheem txhaj tshuaj molding ceev kom ua tau raws li qhov xav tau ntawm ntau lawm.
Vim Li Cas Xaiv Peb
Kev daws teeb meem ib zaug
Nrog kev nplua nuj nyob hauv kev lag luam pwm, peb muab kev pabcuam ib-nres los ntawm cov khoom tsim, pwm tsim mus rau qhov kawg ntau lawm.
Tus nqi zoo
Peb sib zog muab cov nqi sib tw yam tsis muaj kev cuam tshuam rau qhov zoo, muab koj tus nqi rau koj cov peev txheej.
Kev tsim kho tshiab
Peb pab neeg nyob twj ywm hloov tshiab nrog cov thev naus laus zis tshiab thiab cov tswv yim hauv kev tsim pwm, cia peb muab cov kev daws teeb meem tshiab uas txhim kho koj cov txheej txheem molding.
Raws sij hawm xa tuaj
Peb nkag siab qhov tseem ceeb ntawm kev sib ntsib hnub kawg. Peb cov txheej txheem ua tau zoo pab kom peb xa koj cov pwm raws sijhawm, ua kom koj cov sijhawm tsim khoom raws sijhawm.
Yas thawv pwm
Tam sim no muaj ntau hom yas thawv pwm nyob rau hauv kev ua lag luam, cov thawv yas muaj xws li: lub thawv ntim khoom, nyias lub thawv ntim khoom noj ceev, microwave qhov cub yas lub thawv, feem ntau ntawm cov thawv yas yog tsim los ntawm cov zaub mov qib siab PP, PE khoom. , lwm.
Yas thoob pwm
Lub thoob pwm feem ntau yog tsim los ntawm cov khoom siv zoo raw khoom thiab cov cuab yeej txiav, thiab muaj nyob rau hauv cov qauv sib txawv, cov duab thiab qhov ntau thiab tsawg raws li cov kev xav tau ntawm cov neeg siv khoom. Xim thoob, peb ua los ntawm 50 ml mus rau 20L pwm nrog tes, xws li 100 ml, 500 ml, 1 liter, 1 nkas loos, 5 litres, 10 litres.
Crate pwm
Peb tsim crate pwm, xws li txiv hmab txiv ntoo crate, zaub crate, lub raj mis crate, khob cij crate, nyias-wall crate, folding crate, thiab lwm yam. Txhua tus neeg muas zaub xav tau ib tug ntev kev pab cuam lub neej, kev kub ceev crate pwm. Peb feem ntau ntxiv beryllium tooj liab rau lub slider kom luv lub sij hawm voj voog.
Pallet pwm
Xws li ib sab pallet pwm, ob sab pallet pwm, ob txoj hauv kev rau hauv pallet pwm, plaub-txoj kev rau hauv pallet pwm thiab lwm yam.
Dustbin pwm
Peb tuaj yeem tsim thiab tsim cov pwm hauv tsev pwm, kev kho mob plua plav pwm, muaj plua plav pwm pwm. DIN1.2344 steel thiab tooj liab beryllium yog siv rau hauv cov tub ntxhais thiab kab noj hniav ntawm cov pwm. Kev siv beryllium tooj liab txo lub sijhawm txias, thiab nce ntau lawm los ntawm 30-40%.
Thaum koj mus txog lub Hoobkas Plastic Pwm rau kev ua pwm rau cov khoom lag luam koj tuaj yeem xaiv tus qauv pwm rau cov khoom lag luam lossis xaiv mus rau hauv kev xaiv pwm los tsim cov khoom lag luam uas txawv ntawm cov qauv hauv xim, qhov loj, thiab tsos. Ib zaug ntxiv, muaj ob yam tseem ceeb uas koj yuav tsum paub meej txog thaum koj ncav cuag tus tsim pwm.
● Lub hom phiaj uas cov khoom yuav raug siv. Qhov no yuav txiav txim siab hom pwm uas yuav tsum tau ua. Qhov no yog vim hais tias lub hom phiaj yuav pab tau rau kev txiav txim siab hom thermo-teeb yas nrog rau hom pwm zoo kom ua tiav cov khoom siv kawg uas siv cov yas ntawd.
● Tus naj npawb ntawm cov khoom koj xav tias yuav tsim siv cov pwm. Qhov no yog ib qho tseem ceeb dua qhov tseem ceeb raws li tus naj npawb ntawm cov units uas yuav raug tsim los siv cov pwm yuav txiav txim seb hom pwm uas yuav tsum tau tsim. Qhov no yog ib qho tseem ceeb kom tau txais cov pwm zoo thiab cov pwm uas kav ntev.
Dab tsi yog Cov Khoom Tseem Ceeb ntawm Cov Khoom Muag Pwm
Cov khoom tseem ceeb ntawm cov pwm pwm muaj xws li:
Cavity
Cov kab noj hniav yog ib feem ntawm cov pwm uas tsim cov duab sab nraud ntawm cov khoom.
Core
Cov tub ntxhais yog ib feem ntawm cov pwm uas tsim cov duab puab ntawm cov khoom.
Sprue
Lub sprue yog cov channel los ntawm cov yas molten yog nkag rau hauv pwm.
Tus khiav
Tus khiav yog cov channel uas faib cov yas molten los ntawm lub sprue mus rau tus neeg kab noj hniav.
Rooj vag
Lub rooj vag yog qhov qhib uas cov yas molten nkag mus rau hauv kab noj hniav.
Ejector pins
Cov ejector pins yog siv los thawb cov khoom khov kho tawm ntawm cov pwm tom qab nws tau tsim.
Cov cua txias channel
Cov kav dej txias tau muab tso rau hauv cov pwm los xyuas kom meej tias cov yas txias thiab ua kom zoo sib xws thiab ntawm tus nqi raug.
alignment pins
Alignment pins yog siv los xyuas kom meej tias ob lub puab tsaig ntawm cov pwm raug ua kom zoo ua ntej thiab thaum lub sijhawm txhaj tshuaj.
Qhov system
Lub venting system tso cai rau huab cua kom dim ntawm cov pwm thaum lub sij hawm txhaj tshuaj, xyuas kom meej tias cov yas ntim cov pwm tag nrho thiab uniformly.
Cov khoom siv dab tsi feem ntau yog siv los ua cov khoom pwm
Hlau
Hlau yog cov khoom siv dav siv rau cov khoom pwm vim nws lub zog zoo thiab ua haujlwm ntev. Cov hom hlau muaj xws li P20, 718, thiab H13. P20 yog cov cuab yeej qis-alloy steel uas muaj qhov zoo toughness thiab machinability. 718 yog pre-hardened steel nrog ntau dua hardness thiab hnav tsis kam, haum rau kev ua haujlwm siab. H13 yog cov cuab yeej ua haujlwm kub kub uas paub txog nws cov cua kub tsis kam thiab zoo thermal conductivity.
Aluminium
Aluminium yog lwm cov khoom siv nrov rau cov khoom lag luam pwm, tshwj xeeb tshaj yog rau cov khoom ntim qis lossis kev tsim qauv sai. Nws yog lub teeb yuag, muaj thermal conductivity zoo, thiab tso cai rau kom txias mus sai. Txawm li cas los xij, aluminium tej zaum yuav tsis zoo li cov hlau thiab tej zaum yuav muaj kev txwv ntawm cov voj voog uas nws tuaj yeem tiv taus.
Tooj Alloys
Copper alloys, xws li beryllium tooj liab, qee zaum siv rau cov khoom lag luam pwm uas xav tau cov thermal conductivity siab. Cov alloys no tshwj xeeb tshaj yog tsim rau cov ntawv thov uas hloov cov cua sov yog qhov tseem ceeb, xws li hauv kev txhaj tshuaj molding txheej txheem.
Stainless hlau
Stainless hlau paub txog nws cov kev tiv thaiv corrosion thiab feem ntau yog siv rau cov pwm uas tuaj rau hauv kev sib cuag nrog cov ntaub ntawv corrosive lossis ib puag ncig. Nws muab qhov zoo ntawm qhov ruaj khov thiab tsim nyog rau kev tsim cov khoom lag luam nrog cov kev xav tau siab saum npoo.
Yam khoom twg tuaj yeem tsim pwm tsim
Cov khoom pwm muaj ntau yam thiab tuaj yeem tsim tau ntau yam khoom siv. Qee qhov piv txwv ntawm cov khoom uas tuaj yeem tsim tau siv cov khoom pwm muaj xws li:
Plastic Containers:Cov khoom lag luam pwm feem ntau siv los tsim cov thawv yas ntawm ntau qhov ntau thiab tsawg thiab cov duab, xws li cov thawv ntim khoom noj, lub raj mis dej haus, thiab cov hub kom zoo nkauj.
Caps Thiab Kaw:Cov khoom lag luam pwm tsim nyog rau kev tsim cov kaus mom thiab kaw rau lub raj mis, lub raj mis, thiab cov raj, nrog rau lub hau hau, flip-top caps, twj tso kua mis, thiab tshuaj tsuag nozzles.
Cov khoom hauv tsev:Ntau yam khoom siv hauv tsev, xws li cov thoob, hangers, cov thawv ntim khoom, thiab cov tais diav, tuaj yeem ua tau zoo siv cov khoom pwm.
Cov Khoom Ua Si Thiab Ua Si:Cov khoom lag luam pwm feem ntau yog siv los tsim cov khoom ua si yas, lub tsev thaiv, kev sib tw, thiab cov khoom ua si board.
Electronic Cheebtsam:Qee yam khoom siv hluav taws xob, xws li cov khoom sib txuas, rooj plaub, thiab npog, tuaj yeem tsim tau siv cov khoom pwm.
Automotive qhov chaw:Cov khoom siv tsheb yooj yim xws li cov khoom siv sab hauv trim, pob qhov rooj, thiab cov leeg tuaj yeem tsim tau siv cov khoom pwm.
Cov cuab yeej kho mob:Cov khoom lag luam pwm tuaj yeem siv los tsim cov cuab yeej kho mob yooj yim, xws li cov tshuaj txhaj tshuaj, cov vials, thiab cov tshuaj ntsiav tshuaj.
Packing Components:Ntau yam ntim khoom, suav nrog cov pob blister, ntim clamshell, thiab cov tais, tuaj yeem ua los ntawm cov khoom pwm.
Cov Khoom Siv Kho Tus Kheej:Cov khoom lag luam pwm yog tsim los tsim cov khoom xws li tshuaj zawv plaub hau, tshuaj pleev qhov muag, txhuam hniav, thiab xab npum tais diav.
Cov khoom siv tsiaj:Cov khoom siv pwm tuaj yeem siv los tsim cov tais tsiaj, zom cov khoom ua si, cov thawv khib nyiab, thiab lwm yam khoom siv tsiaj yas.
Cov ntaub ntawv qhib:Cov khoom siv pwm pem hauv ntej, cov khoom pwm nram qab, cov khoom siv ntxig, cov khoom siv kab, thiab cov khoom siv sab saum toj;
Qhib ncej:Pem hauv ntej pwm ncej, rear pwm ncej;
Qhib thickness:Qhib thickness ntawm pem hauv ntej pwm kab noj hniav, qhib thickness ntawm lub rear pwm kab noj hniav, thiab qhib thickness ntawm parting kab;
Copper txiv neej:Pem hauv ntej pwm tooj liab txiv neej, rear pwm tooj liab txiv neej, parting kab ntshiab kaum tooj liab txiv neej;
Hlau txiav:Ntxig parting kab, tooj liab txiv neej, inclined saum hauv ncoo txoj hauj lwm;
Khoos phis tawj:Precision gong parting kab, precision gong rear pwm core;
Electric spark:Pem hauv ntej pwm ntxhib, tooj liab txiv neej, txiv neej pwm kab ntshiab lub kaum sab xis, rear pwm pob txha txoj hauj lwm, hauv ncoo txoj hauj lwm;
Drill qhov, pinholes, thiab thimbles; Txoj haujlwm ua txoj haujlwm thiab kab txoj haujlwm siab ncej rau saum lub koob lub qhov thiab qhov dej ntawm qhov pwm;
Oblique sab saum toj, ob sab saum toj koob, nrog rau sab saum toj koob.
●Clear tsim thiab ua haujlwm
●Pro/e los ua cov khoom peb-seem qauv
● Pwm tsim
● Rau hauv cov qauv siv pwm
● Teem tus nqi shrinkage
● Tsim cov khoom ua haujlwm dawb
●Design parting nto
● Muab faib ntim thaiv
● Tshem tawm cov khoom pwm
● Casting pwm
● Qhib pwm
● Hauv CNC milling ua
● Kev ua haujlwm ntawm billet thiab kev txiav txim siab ntawm lub cutter point
● Npaj qhov chaw grooving ntxhib machining cuab tam txoj kev, tseg "0.3"
● Workpiece parameter teeb tsa
●Nto grooving ntxhib machining khoom ua simulation
● Npaj qhov chaw grooving machining cuab tam txoj kev, pwm machining nyob rau hauv qhov chaw
● Npaj qhov sib npaug ntawm qhov sib npaug ntxhib machining cuab yeej txoj kev
● Npaj cov cuab yeej txoj kev rau kev sib npaug ntawm qhov chaw
● Npaj txoj hauv kev rau kev ua tiav ntawm contour contour ntawm nto.
Pwm Xeem Txheej Txheem
♂ Nkag siab cov ntaub ntawv cuam tshuam ntawm pwm:
Nws yog qhov zoo tshaj plaws kom tau txais cov qauv tsim ntawm pwm, tshuaj xyuas kom meej, thiab caw tus kws tshaj lij pwm tuaj koom rau hauv kev sim pwm ua haujlwm.
♂ Ua ntej tshawb xyuas qhov kev sib koom ua ke ntawm kev ua haujlwm ntawm lub rooj zaum ua haujlwm:
Kev saib xyuas yuav tsum tau them rau seb puas muaj khawb, tsis muaj qhov seem thiab loosening, seb qhov kev txiav txim ntawm cov pwm mus rau lub skateboard puas muaj tseeb, seb cov dej channel thiab cov roj yeeb nkab sib koom ua ke, thiab yog tias qhib pwm yog txwv, nws yuav tsum tau cim rau ntawm pwm. Yog tias qhov kev txiav txim siab saum toj no tuaj yeem ua tiav ua ntej dai cov pwm, nws tuaj yeem zam qhov kev pov tseg ntawm lub sijhawm thaum pom qhov teeb meem thaum dai pwm, thiab tom qab ntawd qhov pov tseg ntawm lub sijhawm tshwm sim thaum disassembling pwm.
♂ Thaum txiav txim siab qhov tsim nyog ntawm txhua qhov ntawm cov pwm, nws yog ib qho tsim nyog los xaiv lub tshuab txhaj pwm tsim nyog, thiab yuav tsum tau them nyiaj rau kev xaiv.
(a) Kev txhaj tshuaj muaj peev xwm
(b) Dav ntawm qhov taw qhia bar
(c) Qhov qhib siab tshaj plaws
(d) Txawm tias cov khoom siv ua tiav. Tom qab txhua yam tau lees paub tias tsis muaj teeb meem, cov kauj ruam tom ntej yog dai cov pwm. Thaum dai, yuav tsum tau them nyiaj mloog kom tsis txhob tshem tawm tus nuv ua ntej xauv tag nrho cov clamping daim hlau thiab qhib lub pwm, thiaj li tsis txhob loosening los yog tawg cov clamping daim hlau thiab ua rau cov pwm poob.
Tom qab cov pwm raug teeb tsa, cov cuab yeej ua haujlwm ntawm txhua qhov ntawm cov pwm yuav tsum tau ua tib zoo xyuas, xws li seb qhov kev txiav txim ntawm cov skateboard, thimble, cov hniav tshem tawm cov qauv thiab kev txwv hloov yog qhov tseeb. Thiab ua tib zoo saib seb lub injector nozzle thiab qhov chaw nres nkoj pub tau zoo li cas. Cov kauj ruam tom ntej yog ua tib zoo saib xyuas cov pwm kaw qhov kev txiav txim. Nyob rau lub sijhawm no, pwm kaw lub siab yuav tsum tau qis dua, thiab ua tib zoo saib seb puas muaj kev txav tsis tu ncua thiab cov suab nrov txawv txav hauv phau ntawv thiab tsis tshua muaj pwm kaw qhov kev txiav txim.
♂ Ua kom pwm kub:
Raws li kev ua tau zoo ntawm cov khoom siv raw siv hauv cov khoom tiav thiab qhov loj ntawm cov pwm, qhov tsim nyog pwm kub tswj tshuab raug xaiv los tsa qhov kub ntawm pwm mus rau qhov kub thiab txias uas yuav tsum tau ua.
Tom qab pwm kub nce, nws yog ib qho tsim nyog yuav tsum tau xyuas qhov kev txiav txim ntawm txhua qhov, vim tias cov hlau yuav ua rau muaj qhov tshwm sim ntawm clamping tom qab thermal expansion, yog li nws yuav tsum tau them sai sai rau qhov zawv zawg ntawm txhua qhov kom tsis txhob strain thiab vibration.
♂ Yog tias txoj cai tswj kev sim tsis tau siv hauv lub Hoobkas, peb xav tias tsuas yog ib qho xwm txheej tuaj yeem hloov kho ntawm ib lub sijhawm thaum kho cov kev sim ntsuas kom paub qhov txawv qhov cuam tshuam ntawm ib qho kev hloov pauv ntawm cov khoom tiav.
♂ Raws li cov khoom siv raw, ua cov khoom ci ci ntawm cov khoom qub siv.
♂ Tib cov ntaub ntawv raw yog siv kom deb li deb tau rau kev kuaj pwm thiab kev tsim khoom loj rau yav tom ntej.
♂ Tsis txhob sim cov pwm nrog cov ntaub ntawv thib ob, yog tias muaj xim xav tau, koj tuaj yeem npaj cov xim kuaj ua ke.
♂ Kev ntxhov siab sab hauv thiab lwm yam teeb meem feem ntau cuam tshuam rau kev ua haujlwm thib ob, yuav tsum tau sim tom qab kev ruaj ntseg ntawm cov khoom tiav tom qab cov pwm ua haujlwm thib ob hauv qhov qeeb kaw, kho qhov kaw siab, thiab ua haujlwm ntau zaus, saib seb puas muaj pwm. siab tsis sib xws, kom tsis txhob muaj cov khoom tiav burring thiab pwm deformation.
Tom qab kuaj xyuas cov kauj ruam saum toj no, txo qhov kaw nrawm thiab kaw lub siab, teeb tsa kev ruaj ntseg buckle thiab ejection stroke, thiab tom qab ntawd kho qhov kaw nrawm thiab kaw nrawm. Yog hais tias qhov kev txwv hloov nrog qhov siab tshaj plaws stroke tau koom nrog, qhov tuag qhib stroke yuav tsum tau kho me ntsis luv luv, thiab lub siab ceev tuag qhib qhov kev txiav txim yuav tsum raug txiav tawm ua ntej qhov siab kawg tuag qhib stroke. Qhov no yog vim lub fact tias thaum lub sij hawm tag nrho qhib stroke ntawm pwm, lub high-speed motion stroke ntev tshaj qhov tsawg-ceev ib. Cov neeg kho tshuab ejector pas nrig ntawm lub tshuab yas yuav tsum tau kho tom qab tag nrho ceev pwm qhib qhov kev txiav txim, kom tsis txhob deformation ntawm thimble phaj los yog stripping phaj.
Thov xyuas cov hauv qab no dua ua ntej ua thawj pwm txhaj tshuaj:
(a) Txawm hais tias kev noj zaub mov ntev dhau los lossis tsis txaus.
(b) Txawm hais tias lub siab yog siab dhau lossis qis dhau.
(c) Txawm hais tias lub filling ceev ceev dhau los yog qeeb dhau.
(d) Txawm tias lub voj voog ua haujlwm ntev dhau los lossis luv dhau. Txhawm rau tiv thaiv cov khoom tiav luv luv, tawg, deformation, ntug raw thiab txawm tias puas rau pwm.
